TD-S316E-E

Storage Server


TD-S316E-E is a 16-disk enterprise mass storage server specially designed for video surveillance industry. It adopts the latest intel C232 chipset, integrated intel Xeon E3-1220V5 high- performance multi-core processor and assorted advanced data processing and transmission technologies. Due to its low cost, simple deployment, flexible expansion, powerful performance, user-friendly interface design, good compatibility and high reliability, abundant data storage and strong management capability, it can meet the requirements of various large and medium sized video surveillance systems.

It can be widely used in security cities and intelligent cities, including banking, transportation, public security, enterprise and public institution and so on.


  • TD-S316E-E

Introduction

Specification

Accessories

Downloads

Features

High Performance

   Integrated Intel Xeon E3-1220V5 high-performance 4 core processor, up to 8GT/s data transfer rate, 64 bit expansion, I/O acceleration, Turbo, Hyper-Threading Technology

   4 memory card slots, up to 64GB DDR4-1866/2133MHz ECC

   2 gigabit Ethernet ports; supports I/OA technology; supports link aggregation and binding redundancy; supports iKVM;IPMI×1

   12Gbps SAS Expander, 12Gbps RAID card (RAID0,1,5,6 supported)

   Adpots 6 GB SAS expander chip

High Reliability

   16 *3.5 inch hot-pluggable HDD slots and 2 built-in 2.5 inch HDD slots, up to 256TB

   3 control expansion slot: 1*PCI-E3.0x16(x8);1*PCI-E3.0x8; 1*PCE-E3.0x8(x4)

   550W 1+1 redundant power supply

Easy to Manage

   Monitoring various status of the storage server, such as connection status, network status, hardware status and so on; judging the fault level according to the buzzer sound; timely recording event information and operation logs of the device; providing full solution of real-time monitor and alarm of the device

   Independent IPMI interface; supports iKVM, remote startup and shutdown and software installation service

   Provide TPM interface which supports TPM standard security chip, so that the device can be protected effectively in case of the illegal user access

   Embedded device access and transfer modules without extra transfer server access

   Its transfer server doesn’t rely on platform, so the recording will not be interrupted even if the network of the platform server is disconnected

Dimension

CPUIntel Xeon Processor E3
OSLinux
Memory8GB DDR4 ECC,
up to 64GB DDR4 ECC memory
HDD3.5 inch SATA x 16 (hot-pluggable); built-in 2.5 inch SATA x 2
HDD InstallationIndependent HDD bracket
CapacityUp to 256TB (max.16T per HDD)
RAIDHardware RAID; support RAID0, 1, 5, 6
Expansion1*PCI-E3.0x16(x8);1*PCI-E3.0x8;1*PCE-E3.0x8(x4)
Network CardIntegrated I210-AT dual gigabit network cards, load balancing and if one is offline, the other will replace
IPMIASPEED AST2400 BMC, independent IPMI interface; support iKVM
Monitor ControlIntegrated display controller
ProtocolSupport TCP / UDP / RTSP protocol
SearchBuilt-in index, accurate to second-level
PerformanceUp to 700Mbps incoming, 700Mbps recording and 96Mbps playback
Up to 700Mbps incoming, 700Mbps recording and 96Mbps live view
Way of ManagementWEB management, seamless access to NVMS
Capability of ManagementRAID management, record management, system log as well as alarm processing
SecuritySupply TPM interface; TPM module installation supported
Interface1× VGA, 6× USB(4 in the real panel and 2 in the front panel), 2× RJ 45, 1× IPMI, 1× RS 232
Power Supply550W 1+1 redundant power supply, 100~240V-7~3.4A / 50~60Hz
TemperatureWorking: 10°C to 35°C; standby: –40°C~+55°C(ambient)
Relative HumidityWorking: < 90% RH(35°C)
NoiseWorking: < 50Dba
ESDEach item conforms to Intel ambient temperature test standard 15KV
