TD-3532B8-A2/TD-3564B8-A2
32/64 CH HD NVR
TD-3500B8-A2 series supports 32 /64CH 12MP / 8MP / 6MP / 5MP / 4MP / 3MP / 1080P / 1280 × 1024 / 960P /720P high definition IP video input, which adopts the most advanced SOC technique to ensure high definition recording in each channel and realize outstanding robustness of the system. TD-3500B8-A2 series supports 32/64 CH IP input, simultaneous 16 CH playback, and 4K high definition display. The series of products can meet different security requirements of home, financial, commerce, enterprise, transportation and government, etc.
Introduction
Specification
Accessories
Downloads
Features
Support 32/64CH 12MP /8MP / 6MP / 5MP / 4MP / 3MP / 1080P / 1280 × 1024 / 960P / 720P IP input
H.265S/H.265+/H.265/H.264 coding
Intuitive and user-friendly Graphic User Interface ( GUI ), Windows style operation by mouse
Multi-mode recording: manual / timer / motion / sensor/smart events
Playback : 16 CH simultaneous playback
Search : time slice, time, event, tag, smart and target database search
Support face detection and comparison
Support multiple VCA (Video Content Analytics) events, such as object abandoned/missing, region intrusion, tripwire, video exception, etc.
Support POS information overlay on live view and playback
Support RAID0, 1, 5, 6, 10
Express and flexible backup via USB, network and so on
Pentaplex : preview, record, playback, backup and remote access
DHCP, DDNS, PPPoE network protocol
Compatible with third-party IPCs, such as ONVIF, Hikvision, etc.
Remote control via Web Client or CMS : preview, playback, backup, PTZ and configuration
Dual stream technology for local storage with high definition, remote network transmission and remote surveillance with mobile device
Multi-user online simultaneously
Authorization management, log view and device status view
4K output, true high resolution display
Support PTZ preset and auto cruise, up to 255 presets and 8 cruises
Support NAT function and QRCode scanning by mobile phones
Powerful mobile surveillance by smart phones with iOS and Andriod OS
Dimension
| Model | TD-3532B8-A2 | TD-3564B8-A2 | |
| System | OS | Embedded Linux | |
| Video | IP Video Input | 32 CH IPC input | 64 CH IPC input |
| Incoming Bandwidth | 320Mbps | 640Mbps | |
| Outgoing Bandwidth | 320Mbps | Display Priority: 128Mbps Network Priority: 640Mbps | |
| IP Video Input Resolution | 12MP/8MP/6MP/5MP/4MP/3MP/1080P/1280×1024/960P/720P/960H/D1/CIF | ||
| Output | HDMI1 : 3840 × 2160@60fps / 3840 × 2160@30fps/ 1920 × 1080 / 1280 × 1024 / 1024 × 768 | ||
| HDMI2: 1920 × 1080 / 1280 × 1024 / 1024 × 768 | |||
| HDMI3: 1920 × 1080 / 1280 × 1024 / 1024 × 768 | |||
| HDMI4: 1920 × 1080 / 1280 × 1024 / 1024 × 768 | |||
| VGA × 1 : 1920 × 1080 / 1280 × 1024 / 1024 × 768 | |||
| Multi-screen Display | 1/4/6/8/9/13/16/25/32/36 | 1/4/6/8/9/13/16/25/32/36/64 | |
| Compression | H.265S/H.265+/H.265/H.264 | ||
| Audio | Network Input | 32 CH | 64 CH |
| 2-way Audio | RCA × 1 | ||
| Local Output | RCA × 1 | ||
| HDMI Audio Output | Yes | ||
| Compression | G.711(U/A) | ||
| Record | Record Stream | Dual stream recording | |
| Resolution | 12MP/8MP/6MP/5MP/4MP/3MP/1080P/1280×1024/960P/720P/960H/D1/CIF | ||
| Frame Rate | 25fps (PAL) / 30fps(NTSC) | ||
| Mode | Manual, timer, motion, sensor, smart events | ||
| Playback | Simultaneous Playback | Max 16 CH | |
| Search | Time slice / time / event / tag search | ||
| Smart Search | Highlighted color to display the camera record in a certain period of time, different colors refers to different record events | ||
| Decoding Capability | Live/Playback | 1CH 12MP/ 4CH 5MP/9CH 720P/16CH 720P | |
| Alarm | Mode | Manual, sensor, motion, exception, smart events | |
| Input | 16 CH local alarm input; IPC alarm input supported | ||
| Output | 4 CH | ||
| Face | Face Detection Performance (AI by IPC) | 32 CH | 64 CH |
| Face Detection Performance (AI by Device) | 4CH | ||
| Face Match Performance | 8 CH | 16 CH | |
| Comparison Capability | 48 pictures / second | 36 pictures / second | |
| Face Picture Database | 32 libraries | ||
| 10000 Face Pictures | |||
| Face Picture Search | Search by picture is supported | ||
| Database Management | Add, modify, delete and search face pictures | ||
| Face Picture Adding | Add face pictures through APP, WEB and external import | ||
| External face picture enrollment | Resolution：128 x 128 ～ 1920 x 1080 | ||
| Size：less than 70KB | |||
| Format : jpg, jpeg | |||
| Face Picture Comparison | Support common, allow list and block list alarm | ||
| Face Track | Yes | ||
| Map of Face Track | Reolution：≤ 2560 x 1920 | ||
| Size：≤ 512KB | |||
| Format : jpg, jpeg | |||
| Statistic Graph of Face Information | Bar graph | ||
| Statistic Mode of Face Information | Statistics by day, week, month, quarter as well as customized time period | ||
| Network | Interface | RJ45 10 / 100 / 1000 Mbps × 2 | |
| Protocol | TCP / IP, PPPoE, DHCP, DNS, DDNS, UPnP, NTP, SMTP, HTTP, HTTPs, 802.1x, RTSP, ONVIF | ||
| Client Connection | Max. 20 users access | ||
| Mobile Device | OS | iOS, Andriod | |
| Storage | HDD Interface | SATA × 8, max 10T per HDD; e-SATA × 1 | |
| RAID Type | RAID0, 1, 5, 6, 10 | ||
| Backup | Local Backup | U disk, USB mobile HDD | |
| Network Backup | Yes | ||
| Port | USB | USB 2.0 × 2, USB 3.0 × 1 | |
| Remote Controller | Optional | ||
| RS 485 | Yes (full-duplex), connect to PTZ or keyboard | ||
| Others | Power Supply | ATX 200W | |
| Consumption | ≤ 50W ( without HDD ) | ||
| Dimensions | 445mm×436mm×90mm | ||
| Working Environment | -15 ～ 50 ℃，Humidity: 10% ～ 90% | ||
| Certificate | CE, FCC | ||
| Environmental Protection | Directive EU RoHS, WEEE(2012/19/EU) , Directive 94/62/EC and REACH(EC1907/2006) | ||
