TD-6528M3(D/PE/AR2)

Outdoor 8x2MP Stitched 360° Panoramic Network IR Dome Camera


TD-6528M3(D/PE/AR2)   Outdoor 8x2MP Stitched 360° Panoramic Network IR Dome Camera, with power adaptor, bracket, IP66/IK10


  • TD-6528M3(D/PE/AR2)

Introduction

Specification

Accessories

Downloads

Features

 Eight 1080P video modules to stitch one 16MP, 360°surrounded video stream.

 16MP (4096×1800×2) resolution, 25/30fps real-time

 One IP address, One Video Interface, similar with One IPC, easy to learn, management, and deployment

 One Cable (PoE++), One bracket and One Panoramic camera, easy to install, reducing TOC (Total own cost)

 Advanced real-time stitching technology without geometry, brightness and color gap

 6th gen Starlight &HDR technology (0.008lux@F2.0 AGC on) provides vivid color at most scenarios.

 360°(H) × 90°(V) circular IR illumination, up to 20m in radius.

 Programmable VCA: human/vehicle detection, intrusion, line crossing, etc.

 4 Tops Deep-learning AI engine,8Gb DDR for more AI algorithm updates.

 Alarm driven by multi-rules: cross line, intrusion, device error, etc.

 ONVIF specifications, interoperability between network video products regardless of manufacturer

 Full Interface: RJ45, SD Card, Alarm, Audio, Reset

 - 30°C~55°C (-22 °F ~ 131 °F), Built-in heater and fan, IP66 waterproof, IK10, Metal case.

 Support PoE++(802.3.bt, class6) and DC24V / AC24V

 Support Virtual reality (VR) linkage, e-tags, e-map application with TVT VMS

Dimension

Camera Module
Image sensor1/2.8” progressive scan CMOS image sensor x8
Mini. IlluminationColor0.008Lux @ (F2.0,AGC ON)B/W0.008Lux @(F2.0AGC ON);0Lux with IR
Image settingImage vertical rotation, Saturation, Brightness, Contrast, Sharpness, AGC, and AWB adjusted by client software/browser
Shutter Speed1/1 s – 1/100,000 s
White BalanceAuto/Manual/Indoor/Outdoor
GainAuto/Manual
Day & NightIR Cut filter
Privacy Mask8 Programmable privacy masks
Image Enhancement3D DNR, Digital zoom, Logo picture Overlay
Vertical RotationManual adjustment, 8 pitches,  45°per pitch
Lens
Focus length3.3mm,x8
ApertureF2.0
FOVPanoramic image: Horizontal FOV: 2x180°(360°)Vertical  FOV: 85°
Working distance1.0m ~ INF
IR
IR Range20m in radius,360°(H) × 90°(V)
Smart IRYes
Network
Max Resolution8192 ×1800, 25/30fps
Main stream8192 ×1800 , 3840 × 1680 , 2784 × 1200 (1~30fps)
Sub stream:2048 × 896, 1280 × 560 , 704 × 320 (1~30fps)
Third stream:704 × 320 ( 1~30fps )
Video compressionH.265/H.264/ MJPEG
Audio compressionG.711 A/U
ProtocolsHTTP, HTTPS, IPv4/IPv6, 802.1x, QoS, FTP, SMTP, UPnP, SNMP,DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, DHCP, PPPoE
Simultaneous live viewUp to 6 channels
User / HostUp to 16 users, 3 levels: Administrator, Advanced User and Normal User
Security MeasuresUser authentication (ID and PW), Host authentication (MAC address);
HTTPS encryption, IEEE802.1x port-based network access control; IP address filtering
Smart Features
Basic eventMotion detection, video tampering alarm,
exception (network disconnected, IP address conflict, SD full, SD error)
Smart DetectionUp to 8 regions configurable: Human/vehicle detection and classification, Face comparison, Intrusion detection,
 Line crossing detection,Region entrance detection, Region exiting detection, Scene change detection, etc.
ROIUp to 4 regions configurable
Alarm LinkageUpload to FTP/Memory card, send email, trigger alarm output, trigger recording, trigger snapshot
System Integration
Alarm Interface1CH alarm input; 1CH alarm output
Audio Interface1CH audio input, 2 to 2.4v[p-p] 1kΩ±10%; 1CH audio output (line out), impedance: 600Ω
Network Interface1 RJ45 10M/100M/1000M Adaptive Ethernet (Support PoE++(802.3.bt,class 6))
StorageBuilt-in memory card slot, support microSD/SDHC/SDXC, up to 256G
APIONVIF, support TVT SDK and third-party management platform
ClientTVT NVR N9000 1.4.6, TVT NVMS 2.0(Support VR, e-Tag, e-map application)
Web BrowserIE8-11
General
PowerAC24V,DC24V,PoE++ (802.3.bt, class 6), (Max 45W, include IR on, Fan on and Heater on)
Working condition-30°C ~ 55°C (-22 °F ~ 131 °F),90%RH less (non-condensing),Cold start at - 20°C
Storage condition-40°C ~ 70°C ;≤ 95% RH
ProtectionIP 66, IK10, 6000V Lightning Protection, Surge Protection and Voltage Transient Protection
MaterialCamera body: Aluminum Alloy; Bubble and IR cover: Plastic
Dimensions273mm x H 180mm( 10.7” x 7”)
WeightNet weight Approx. 2.0Kg(4.4 lb)
CertificationIK10(exclude plastic cover), IP66,ROHS, CE, FC
