TD-8583IE2N(PE/32M/AR20)
8MP 32X 200m IR Network Smart PTZ
TD-8583IE2N(PE/32M/AR20) PTZ camera which adopts SONY latest images sensor, with powerful 32x optical zoom lens, could deliver ultra-high definitions 4K(3840x2160@30fps) image over a wide open area. The H.265 video compression reduces bit rate down to 50% of H.264 without loss. With its built-in 1.5Tops AI engine, the PTZ could detect and classify max 15 objects per scene. When any of them intrude restricted areas, the PTZ camera will trace, zoom fit in center of screen, snap and record and trigger alert. The rotation speed of gimbals is improved for tracing fast object. The IR brightness is enhanced 250%, with F1.2 large aperture, which improves night vision distance beyond 200m. This PTZ conforms to the ONVIF specifications ensuring interoperability between network video products regardless of manufacturers, and also complies with NDAA 2019.
Introduction
Specification
Accessories
Downloads
Features
1/2.8″ SONY progressive scan CMOS
Up to 3840x2160 resolution
Mini illumination:
Color: 0.01 lux @ (F1.2 AGC ON)
0 Lux with IR
32x optical zoom, Accurate and fast focusing
HDR, 3D DNR, Smart IR
IR distance beyond 200m
Smart H.265+/H.265/H.264+/H.264
Intelligent Video content analytics
Smart tracking of human/vehicle
Smart detection and perimeter protection
ONVIF, API and SDK
PoE++, DC24V, AC24V power self-adaptive
IP66, -40°C~65°C, Aluminum Alloy & Plastic
Dimension
| Camera Module | ||||
| Image sensor | 1/2.8″SONY latest progressive scan CMOS | |||
| Mini. Illumination | Color：0.01Lux @ (F1.2，AGC ON)；B/W：0.002Lux @(F1.2，AGC ON);0Lux with IR | |||
| Image setting | Flip, Mirror, Saturation, Brightness, Contrast, Sharpness, AGC, etc. adjusted by client | |||
| Shutter Speed | 1/1 s – 1/100,000 s | |||
| White Balance | Auto/Manual/Indoor/Outdoor | |||
| Gain control | Auto/Manual | |||
| Day & Night control | Auto/Manual , time schedule | |||
| Iris control | Auto/Manual | |||
| SNR | ≥55dB | |||
| 3D DNR | Auto/Manual | |||
| AE Enhancement | BLC, HLC, WDR | |||
| Privacy Mask | 24 areas, up to 8 mask in the same frame | |||
| Picture overlay | Logo picture could be overlaid on video with 128x128pixels,24bits BMP format | |||
| OSD overlay | max 15 characters/line, 8 lines, white or red font color | |||
| Lens | ||||
| Focus length | f=4.8-154mm lens,32x optical zoom | |||
| Zoom Speed | Approx. 4.6s (optical zoom, wide-tele) | |||
| Field of View | Horizontal: 61.3° ~2.18° ;Vertical: 36.9° ~ 1.22° ; Diagonal: 68.4° ~ 2.5° (wide-tele) | |||
| Working distance | wide: 1.0m ~ INF; tele: 1.5m ~ INF | |||
| Iris | DC IRIS (hall sensor, 16stops) F1.2 ~ F4.4 (wide-tele) | |||
| IRCut type | Removable IRCut filter | |||
| DORI distance | Detect | Observe | Recognize | Identify |
| 3528m(11575 f.t.) | 1400m(4593 f.t.) | 700m(2296f.t.) | 350m(1148f.t.) | |
| PTZ | ||||
| Pan Range | 360°endless | |||
| Pan speed | Configurable, from 0.1~120°/s; Preset speed: 150°/s | |||
| Tilt Range | From -5° to 90°,auto flip | |||
| Tilt Speed | Configurable, from 0.1°~ 120°/s, Preset speed: 150°/s | |||
| Proportional Zoom | Yes | |||
| Preset | 360 | |||
| Cruise | 8 cruises, up to 16 presets for each cruises | |||
| Trace | 4 traces, record time over 3 minutes for each trace | |||
| Power off memory | Support | |||
| Action mode | Preset/Cruise/Trace/Auto Scan/Random Scan | |||
| 3D Positioning | Support | |||
| PTZ Position Display | Support | |||
| Schedule Task | Preset/Cruise/Trace/Random Scan/Boundary Scanning /Dome reboot | |||
| IR | ||||
| IR Distance | 200m (656 f.t.) | |||
| Smart IR | Yes | |||
| Network | ||||
| Max Resolution | 3840x2160 | |||
| Main stream | 50Hz: 25fps: 3840× 2160,2560× 1440,1920× 1080,1280× 960,1280× 720, | |||
| 60Hz: 30fps:3840× 2160,2560× 1440,1920× 1080,1280× 960,1280× 720 | ||||
| Sub stream | 50Hz: 25fps: (704 × 576, 640 × 480, 352 × 288); | |||
| 60Hz: 30fps (704 × 480, 640 × 480, 352 × 240) | ||||
| Third Stream | 50Hz:25fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288) | |||
| 60Hz:30fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240) | ||||
| Video compression | H.265/H.264+/H.264/MJPEG | |||
| H.264 Standard | H.264/AVC codec BP/MP/HP, Level 5.1 | |||
| H.265 Standard | H.265/HEVC codec MP, level 5.0 | |||
| Video Bit Rate | 64 Kbps to 16Mbps | |||
| Audio compression | G.711 A/U | |||
| Audio Bit Rate | 64K bps | |||
| Protocols | HTTP, HTTPS, IPv4/IPv6, 802.1x, QoS, FTP, SMTP, UPnP, SNMP,DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, DHCP, PPPoE | |||
| User / Host | Up to 16 users, 3 levels: Administrator, Advanced User and Normal User | |||
| Security Measures | User authentication (ID and PW), Host authentication (MAC address); HTTPS encryption, IEEE802.1x port-based network access control; IP address filtering | |||
| Smart Features | ||||
| Basic event | Motion detection, Video tampering alarm, Exception(Network disconnected, IP address conflict, SD full, SD error) | |||
| Face recognize | Detecting max 15 faces at same scene. Detecting, tracking, capturing | |||
| Road traffic | Vehicle detecting and tracking | |||
| Smart Detection | Tripwire, Bi-directional tripwire, Illegal intrusion detection, Region entrance detection, Region exitance detection, Unattended baggage detection, Object removal detection, etc. | |||
| Smart Tracking | smart tracking of human or vehicle, auto/manual | |||
| System Integration | ||||
| Alarm Interface | 1 Alarm input(Dry contact); 1 Alarm output | |||
| Audio Interface | 1 audio input(MIC in); 1 audio output, line level, impedance,600Ω | |||
| Alarm Linkage | Alarm actions, such as Preset, Cruise, Track, Memory Card Video Record, Trigger Recording, Notify Surveillance Center, Upload to FTP/Memory Card, Send Email, etc. | |||
| Network Interface | 1 RJ45 10M/100M Adaptive Ethernet ,Support PoE++( 802.3.bt,class 6) | |||
| SD Card | On-body MicroSD chamber, up to 256G | |||
| RS 485 | N/A | |||
| BNC | N/A | |||
| Speaker &Mic | N/A | |||
| Reset button | Yes | |||
| Heater | Yes | |||
| Fan | Yes | |||
| Water removal | Remove water-drops by quick spinning | |||
| API | ONVIF, support TVT SDK and third-party management platform | |||
| Client | TVT N9000 1.4.5, TVT NVMS 2.0; and the third-party client | |||
| Web Browser | IE8-11 | |||
| General | ||||
| Culture | 16 languages: Czech; English, German ; Hungarian ; Italian ; Japanese ; Korean ; Portuguese, Polish; Russian, Romanian, Spanish; Spanish(Mexico);Simplified Chinese; Turkish; Traditional Chinese. | |||
| Power Supply | DC24V/AC 24V ±25%, PoE++ (802.3.bt, class 6), max 34W include IR ON+PTZ working | |||
| Working condition | -40°C ~ 65°C (-40°F ~ 149°F), Cold start at - 30°C; 90%RH | |||
| Storage condition | -40°C ~ 70°C ; ≤ 95% RH | |||
| Protection | IP66, 6000V Lightning Protection, Surge Protection and Voltage Transient Protection | |||
| Shield Material | Aluminum Alloy + Plastic | |||
| Dimensions | Φ196mm × 317mm ( Φ 7.7 inch × 12.5 inch) | |||
| Net Weight | Approx. 3.7 Kg (8.31 lb.) | |||
| Certification | IP66,IK10(excluding glass window),ROHS,CE,FC | |||
