TD-E2137-PE/TP/WF

Video Intercom Indoor Station



  • TD-E2137-PE/TP/WF

Introduction

Specification

Accessories

Downloads

Features

7 inch IPS touch screen

A maximum of 6 indoor stations can be installed in the same room

Support live preview of the linked camera

Support snapshot when calling via door station (micro SD card required)

Support mute notification function

Use the advanced noise suppression and echo cancellation technology to ensure high sound quality

8CH zone alarm access function

Self-define door opening password

Support 2.4G WIFI

Support 1CH 12V200mA power output for powering up a sensor

Dimension



SystemOperating SystemLinux
DisplayDisplay Screen7 inch IPS touch screen
Display Resolution1024 × 600 , brightness:300 cd/m2
Operation MethodCapacitive touch screen
VideoVideo InputMax. 4CH videos can be viewed simultaneously
Network Input Resolution6MP/5MP/4MP/3MP/1080P/1280×1024/960P/720P/960H/D1/CIF
CompressionH.265+/H.265/ H.264
AudioLocal InputBuilt-in microphone
Local OutputBuilt-in speaker
CompressionG.711(U/A)
RecordResolutionUp to 2MP
Frame RateNTSC: 30fps; PAL:25fps
PlaybackSimultaneous PlaybackMax.1CH
PerformanceLinked IPCMax. 16 CH
Linked Indoor ExtensionsMax. 5
NetworkInterfaceRJ 45 100 Mbps self-adaptive Ethernet port × 1
Wireless NetworkWiFi 802.11b/g/n
ProtocolTCP / IP, DHCP, DNS, NTP, etc.
Incoming/Outgoing Bandwidth40/40Mbps
InterfaceAudioBuilt-in speaker and microphone, support noise suppression and echo cancellation
StorageBuilt-in micro SD card slot, up to 256GB
ResetYes
Alarm Input8CH
Wi-FiYes,2.4G Wi-Fi
Unlocking ButtonYes
RS 485Reserved
Power OutputDC12V 200mA (only available when DC12V power supply is used)
OthersPowerDC12V/POE
Power Consumption< 6W
Dimensions(mm)180.6 135.6 26.8
Weight (net)Approx.0.36kg
InstallationWall mounting
Working Environment-20℃ ~50℃, Humidity: less than 95% (non-condensing)
CertificateCE, FCC
Environmental ProtectionComplies with Directive EU RoHS, REACH and WEEE
