TD-3308H2-8P-B2-B
8CH PoE NVR
TD-3308H2-8P-B2-B supports 8 CH 16MP / 12MP / 8MP / 6MP /5MP / 4MP /3MP / 1080P / 1280x1024/960P/ 720P high definition IP input, which adopts the advanced SOC technique to ensure high definition recording in each channel and realize outstanding robustness of the system.
TD-3308H2-8P-B2-B integrates with 8 PoE network ports and supports 8 CH IPC direct connection to NVR , simultaneous 8 CH playback, and 4K high definition display. The series of product can meet different security requirements of home, financial, commerce, enterprise, transportation and government, etc.
Introduction
Specification
Accessories
Downloads
Features
Supports 8 CH 16MP/12MP/8MP/6MP/5MP/4MP/3MP/1080P/1280×1024/960P/720P/960H/D1/CIF IPC Input
H.265S/H.265+/H.265/H.264
Intuitive and user-friendly Graphic User Interface ( GUI ), Windows style operation by mouse
Multi-type recording: manual / timed / motion / sensor / POS / AI recording
Playback : 8 CH simultaneous playback
Search : time slice, time, event, tag and smart search
Supports face detection and comparison
Supports multiple VCA (Video Content Analytics) events, such as object abandoned/missing, region intrusion, tripwire, video exception, etc.
Supports license plate recognition
Supports POS information overlay on live view and playback
Pentaplex : preview, record, playback, backup and remote access
DHCP, DDNS, PPPoE network protocol
Compatible with third-party IPCs, such as ONVIF, Hikvision, etc.
Remote control via Web Client or CMS : preview, playback, backup, PTZ and configuration
Supports 8CH PoE IPC direct connection to NVR via PoE ports
Multi-user online simultaneously
Authorization management, log view and device status view
4K output, true high resolution display
Supports PTZ preset and auto cruise, up to 255 presets and 8 cruises
Supports NAT function and QRCode scanning by mobile phones
Powerful mobile surveillance by smart phones with iOS and Andriod OS
Dimension
Model | TD-3308H2-8P-B2-B | |
System | OS | Embedded Linux |
Video | Compression | H.265S/H.265+/H.265/H.264 |
IP Video Input | 8CH IPC input | |
Resolution | 16MP/12MP/8MP/6MP/5MP/4MP/3MP/1080P/1280×1024/960P/720P/960H/D1/CIF | |
Incoming/ Outgoing Bandwidth | 160Mbps / 160Mbps (*when 8 IPCs are directly connected to 8 PoE ports, the incoming/outgoing bandwidth just can reach 80Mbps/80Mbps) | |
*When the AI function of the IPC is enabled, the actual incoming bandwidth (max.bitrate) is more than the set value in the NVR. | ||
Output | HDMI : 3840 × 2160/1920 × 1080 / 1280 × 1024 / 1024 × 768 VGA : 1920 × 1080 / 1280 × 1024 / 1024 × 768 VGA can be set to output the same or different video source with HDMI | |
Multi-screen Display | Main output: 1/4/6/8/9 (live view) AUX output: 1/4/6/8/9 (live view) AI mode (default mode): max 8CH (HDMI and VGA output the same video source, AI by device supported) Independent output mode: max 16CH (HDMI and VGA output different video sources, AI by device not supported) | |
Audio | Network Input | 8 CH IPC audio input |
2-way Audio | RCA × 1 | |
Local Output | RCA × 1 | |
Compression | G.711(U/A) | |
Record | Resolution | 16MP/12MP/8MP/6MP/5MP/4MP/3MP/1080P/1280×1024/960P/720P/960H/D1/CIF |
Frame Rate | NTSC: 30fps; PAL: 25fps | |
Playback | Simultaneous Playback | Max 8 CH |
Search | Time slice / time / event / tag / smart search | |
Smart Search | Highlighted color to display the camera record in a certain period of time, different colors refers to different record events | |
Function | Play, pause, FF, FB, digital zoom, etc. | |
Decoding Capability | Live View/ Playback | 1×16MP / 4×4MP/10×1080P (main output: 8×1080P + aux. output: 2×1080P) |
Alarm | Mode | Manual, sensor, motion, exception, smart events, etc. |
Input | 8 CH local alarm input | |
Output | 4 CH | |
Triggering | Record, snap, preset, e-mail, etc. | |
Face | Face Detection Performance (AI by IPC) | 8 CH |
Face Detection Performance (AI by Device) | 2 CH (2MP) | |
Face Match Performance | 6 CH | |
Comparison Capability | 18 pictures / second | |
Face Picture Database | 32 libraries 10000 Face Pictures | |
Face Picture Search | Search by picture is supported | |
Database Management | Add, modify, delete and search face pictures | |
Face Picture Adding | Add face pictures through APP, WEB and external import | |
Face Picture Comparison | Supports allow list, block list and stranger match alarm | |
Track | Track display on a map | |
Statistical Graph of Information | Bar graph | |
Statistical Mode of Information | Statistics by day, week, month, quarter as well as customized time period | |
Perimeter Protection | Human/Vehicle Classification (AI by IPC) | 8 CH |
Human/Vehicle Classification (AI by Device) | 2 CH (2MP) | |
Video Metadata | Human/Vehicle Attribute Analysis | Yes (AI by IPC) |
Other Functions | Fisheye | Supports fisheye camera access |
Plate Recognition (AI by IPC) | Yes | |
PoE | PoE Port | RJ 45 100Mbps × 8 |
Standard | IEEE802.3AF/AT | |
Output Power | ≤ 80W | |
Network | Interface | RJ 45 1000 Mbps × 1 |
Protocol | TCP / IP, PPPoE, DHCP, DNS, DDNS, UPnP, NTP, SMTP, HTTP, HTTPs, 802.1x, RTSP, SNMP, ONVIF, etc. | |
Client Connection | Max. 64 users access | |
Mobile Device | OS | iOS, Andriod |
Storage | HDD Interface | SATA × 2, max 10T for each HDD |
Backup | Local Backup | U disk, USB mobile HDD |
Network Backup | Yes | |
External Interface | RS 485 | Yes (full-duplex) |
USB | USB 3.0 × 1 ; USB 2.0 × 2 | |
Remote Controller | Optional | |
Others | Power Supply | DC48V/2.5A |
Consumption | ≤ 20W ( without HDD and PoE power supply ) | |
Certificate | CE, FCC | |
Environmental Protection | Directive EU RoHS, REACH and WEEE | |
Dimensions(mm) | 380 × 268 × 45 ( W × D × H ) | |
Working Environment | -10 ~ 50 ℃,10% ~ 90% humidity |
