TD-B2216S1-PGS TD-B2224S1-PGS TD-B2224S1-PGA
16/24-Ports AI PoE Switch
Introduction
Specification
Accessories
Downloads
Features
AI Watchdog Function
Auto-detect the data communication status of all PoE ports in real-time, and restart PoE IP camera timely if the camera is halted
Auto-Adaption 250m Transmission
Using the latest transmission technology, each port of the switch intelligently judges the transmission distance and automatically adapts 250m transmission, not including 1000M PoE ports
6KV Lightning & 8KV ESD Protection
1000Mbps RJ45 and SFP Uplink Ports
Dimension
| Model | TD-B2216S1-PGS | TD-B2224S1-PGS | TD-B2224S1-PGA |
| Network Parameters | |||
| PoE Ports | 16 × 10/100 Mbps PoE ports(RJ45) | 24 × 10/100 Mbps PoE ports(RJ45) | 24× 10/100/1000 Mbps PoE ports(RJ45) |
| Uplink Ports | 2 × 10/100/1000 Mbps ports(RJ45) | ||
| SFP Port | 1 × 1000Mbps SFP fiber port(Data) | 2 × 1000Mbps SFP fiber ports(Data) | |
| Network Standard | IEEE 802.3, IEEE 802.3u, IEEE 802.3x | ||
| MAC Address Table | 8K | ||
| Switching Capacity | 9.2Gbps | 12.8Gbps | 56Gbps |
| The Frame Filter & Transmission Rate | 14800pps the most for the long distance mode, 148800pps the most for 100M port, 1.488Mpps the most for 1000M port | ||
| Transmission Distance | 100Mbps /10Mbps, Auto-Adaption 250m except the last two PoE ports | 130m | |
| PoE | |||
| PoE Standard | IEEE 802.3af, IEEE 802.3at | ||
| PoE Ports | 1-16 ports | 1-24 ports | 1-24 ports |
| Power Output | PIN:1/2(+), 3/6(-) | ||
| Max. Port Power | 30W | ||
| General Parameters | |||
| Power | AC 100~240V | ||
| Power Consumption | Max. 250W | Max.300W | Max.300W |
| Protection Level | Lightning Protection: 6KV; ESD Protection: 8KV | ||
| Dimensions | 440×180×45mm | ||
| Environment | Operating Temperature: -20℃~60℃ | ||
| Storage Temperature: -40℃~70℃ | |||
| Operating Humidity: 10%~90%Non-condensing | |||
| Storage Humidity: 5%~90%Non-condensing | |||
| Weight (net) | < 2.8kg | < 3kg | < 3kg |
| Installation | Desktop mount; Rack mount | ||
